Product Information
Description
C-200 Commercial/Industrial RO Controller
The Crystal Quest C-200 Microprocessor Controller is a versatile controller for reverse osmosis systems that offer advanced features and options which make it an exceptional choice for large commercial and industrial reverse osmosis systems.The Crystal Quest C-200 Controller has the flexibility to meet many specifications with six (6) switch inputs, five (5) analog inputs, six (6) relay outputs, and two (2) TDS/conductivity inputs. The 4 line by 20 character LCD display provides sensor readings, hours of operation, temperature, alarms, and operating status of the RO system.
Features:
- Universal AC power 80-265 VAC 50/60Hz
- 4-line x 40-character backlit LCD
- 18-key keypad with integral alarm light
- Programmable time delays and set points
- Real-time clock with battery backup
- Non-volatile set-point memory
- Audible alarm with timed alarm silence
- English or metric readings
- Input/output indicator LEDs
- Preprogrammed RO functions
###
Specifications:
- Power: 80-265VAC, 50/60Hz
- Enclosure: 14”x12”x8” NEMA 4X (larger enclosures are required to accept motor starters)
- Feedwater valve relay
- RO and auxiliary pump control relays
- Permeate and feed TDS/Conductivity
- Membrane flush valve relay
- Permeate divert valve relay
- Temperature
- Operating hours
- Low feed pressure switch
- High pump pressure switch
- Pretreatment lockout
- Flowmeter interface for permeate
- RO storage tank switches (1 or 2)
- RO storage tank low switch
- Remote alarm output
- Six (6) switch
- Five (5) 4-20mA analog
- Two (2) Conductivity/Resistivity
- One (1) pH
- One (1) ORP
- Four (4) flow
- Six (6) relay
- One (1) 4-20mA analog
- RS-232
- Modem
- RS-485
- Graphical display
###
Optional Accessories:
- pH, ORP sensor with display and alarm set points
- IEC motor starters and control transformers
- Flow sensors to display flow in GPM or LPM, with % recovery displayed and alarm setpoints for high and low flow rates
- Pressure sensors allowing display on LCD of pressures and differential pressures with programmable setpoints for high, low, and differential pressure alarms
###
Additional Info
| Category | Home & Garden Water Treatment & Coolers Commercial & Industrial Water Treatment |
| SKU | CQE-CV-S200 |
| MPN | |
| Manufacturer | Crystal Quest Water Filters |
| Weight | 0.0 lb |
