24-Volt Valve Actuator. Designed with quality in mind, Intermatic's 24-Volt valve actuators provide reliable control of 2-way and 3-way diverter valves for pool/spa combinations and water features. The water flow can be altered for specific applications through the adjustable cam, which rotates diverter valves to multiple degree settings. The cam settings can be easily adjusted by simply removing the lid.
These valve actuators are compatible with all pool/spa valves currently offered in the inudstry and will retofit into all pool/spa control systems.
Applications: Pools, Spas, Fountains, Water Features
Standard Features:
- Automates compatible diverter valves for pool/spa & pool/water feature combinations
- Adjustable cam rotates diverter valves to multiple degree settings
- Retrofits into all pool/spa control system on the market
- 25ft Cord
Actuator Type: 120 deg, 180 deg, 360 deg, 90 deg
Product Specifications:
Actuator Type
120 deg, 180 deg, 360 deg, 90 deg
Actuator Application
2-Port, 3-Port
Amperage Rating
0.75 A
Frequency Rating
60 Hz
Standards Approvals
CSA Certified
Operating Temperature
14 to 167 deg F
Voltage Rating
24 VAC
Warranty Information
12 Months
