Description
The Waterway Executive 48 pump is thermally protected to extend the life expectancy of the motor with a highly versatile wet end.
Spa Pump Product Features:
- Executive wet end designed specifically for 48-frame motors.
- Large 6-1/2" diameter wet end for higher head pressure.
- 2" intake and discharge.
- Wet end can be rotated for easy installation.
- Thermally protected to extend life expectancy of motor.
- Dimensions (H x W x L): 8.34" x 8.13" x 16.70".
- 4.5Hp and dual speed.
- California Title 20 Compliant.
Product Specifications:
Speed
2 Speed (2-Spd)
Motor Voltage
230v
Drain Plug Location
3,6,9 o`clock
Pump to Motor Foot Types
4a
Suction Style
Center
Suction Connection (Physical Dimension)
3-1/16"od
Suction Connection Type
Male Buttress Thread (mbt)
Suction Pipe Size
2"
Discharge Style
Side
Discharge Connection (Physical Dimension)
3-1/16"od
Discharge Connection Type
Male Buttress Thread (mbt)
Discharge Pipe Size
2"
Horsepower
4.5SPL
Motor Frame
48 Frame Thru-Bolt
Motor Amperage/Wattage
12.7A/3.4A
Manufacturer
Waterway
Pump Model
Executive
Manufacturer Impeller Number
310-4200 (3.0hp)
Volute Fastening Type
8 Screws
Volute/Sealplate Number
315-1240
Manufacturer Wet End Number
310-1910
Warranty Information
12 Months
