Description
The Executive 56 Frame Spa Pump has an executive wet end designed for 56-Frame motors along with two double-shielded ball bearings with moisture-resistant grease for quieter operation and long life. The dual speed motors have insulated windings for increased efficiency and large, highly versatile 6-1/2" diameter wet end for higher head pressure. A split capacitor (start and run) allows for less energy consumption.
Spa Pump Features:
- Executive wet end designed specifically for 56-frame motors.
- 56-frame motor for added strength, cooler operating temperature, and longer motor life.
- Large 6-1/2" diameter wet end for higher head pressure.
- 2" intake for improved flow performance and reduced noise.
- Wet end can be rotated for easy installation.
- Two double shielded ball bearings with moisture resistant grease for quieter operation and longer life.
- Two speed motors have four sets of insulated windings for increased efficiency.
- Dimensions (H x W x L): 9.08" x 8.05" x 14.775".
Product Specifications:
Complete Pump Type
Portable Spa Pump
Speed
2 Speed (2-Spd)
Motor Voltage
115v
Drain Plug Location
4,6,9 o`clock
Pump to Motor Foot Types
9
Suction Style
Center
Suction Connection (Physical Dimension)
3-1/16"od
Suction Connection Type
Male Buttress Thread (mbt)
Suction Pipe Size
2"
Discharge Style
Side
Discharge Connection (Physical Dimension)
3-1/16"od
Discharge Connection Type
Male Buttress Thread (mbt)
Discharge Pipe Size
2"
Horsepower
1.5SPL
Motor Frame
48 Frame Thru-Bolt
Motor Amperage/Wattage
13.3A/4.1A
Manufacturer
AquaFlo/Gecko
Pump Model
Flo-Master XP2e
Manufacturer Impeller Number
91694150
Volute Fastening Type
8 Screws
Volute/Sealplate Number
92770705
Manufacturer Wet End Number
91041815-000
Warranty Information
12 Months
