Description
The Executive 56 Frame Spa Pump has an executive wet end designed for 56-Frame motors along with two double-shielded ball bearings with moisture-resistant grease for quieter operation and long life. The dual speed motors have insulated windings for increased efficiency and large, highly versatile 6-1/2" diameter wet end for higher head pressure. A split capacitor (start and run) allows for less energy consumption.
Spa Pump Features:
- Executive wet end designed specifically for 56-frame motors
- 56-frame motor for added strength, cooler operating temperature, and longer motor life
- Large 6-1/2" diameter wet end for higher head pressure
- 2-1/2" intake for improved flow performance and reduced noise
- Wet end can be rotated for easy installation
- Two double shielded ball bearings with moisture resistant grease for quieter operation and longer life
- Two speed motors have four sets of insulated windings for increased efficiency
- Dimensions (H x W x L): 9.08" x 8.05" x 14.775"
Product Specifications:
Motor Voltage
230v
Speed
1 Speed (1-Spd)
Motor Amperage/Wattage
12.0A
Horsepower
4.0hp
Pump Model
Executive
Suction Pipe Size
2-1/2"
Suction Connection Type
Male Buttress Thread (mbt)
Suction Style
Center
Discharge Pipe Size
2"
Discharge Connection Type
Male Buttress Thread (mbt)
Discharge Style
Side
Motor Frame
56 Frame Thru-Bolt
Drain Plug Location
3,6,9 o`clock
Warranty Information
12 Months
