Description
Aqua-Flo by Gecko's Circ-Master pump takes 24-hour filtration to a new level, delivering the highest GPM of any recirculation pump on the spa industry. Higher GPM allows the Circ-Master to operate a high-flow heating system resulting in increased heating efficiency and up to four times the filtration.
Spa Pump Product Features:
- 48 frame, continuous-duty construction with front and rear, permanently lubricated ball bearings for extended motor life.
- Carbon-graphite self-lubricating seal designed for continuous duty operation.
- 1-1/2" suction and discharge.
- Quick release compression fittings allow for easy installation or maintenance.
- Available in side discharge and center discharge models.
- Available with 115v and 230v motors.
- California Title 20 Compliant.
NOTE: This pump uses an impeller rated at 1.0hp. When installed on a motor that turns at 1725 RPM, the pump becomes 1/15th horsepower.
Product Specifications:
Complete Pump Type
Circulation Pump
Speed
1 Speed (1-Spd)
Motor Voltage
115v
Drain Plug Location
3,6,9 o`clock
Pump to Motor Foot Types
15
Suction Style
Center
Suction Connection (Physical Dimension)
1-11/16"id, 2-7/16"od
Suction Connection Type
Female Pipe Thread (fpt), Male Buttress Thread (mbt)
Suction Pipe Size
1-1/2"
Discharge Style
Center
Discharge Connection (Physical Dimension)
2-7/16"od
Discharge Connection Type
Male Buttress Thread (mbt)
Discharge Pipe Size
1-1/2"
Horsepower
1/15hp
Motor Frame
48 Frame Thru-Bolt
Motor Amperage/Wattage
1.3A
Manufacturer
AquaFlo/Gecko
Pump Model
Circ-Master CMCP
Manufacturer Impeller Number
91693601
Volute Fastening Type
8 Screws
Volute/Sealplate Number
91231402
Manufacturer Wet End Number
91040810-000
Warranty Information
12 Months
Other Details
