Description
Aqua-Flo by Gecko's Flo-Master® XP2e pump is the energy conscious offering within its high performance spa pump line. It's designed for today's large, heavily jetted spas requiring increased flow. The XP2e pump fits within the same envelope as the original XP2 pump, yet provides greater flow while improving the overall energy efficiency of the spa.
Spa Pump Features:
- Fine tuned impeller that moves water through the system with maximum performance.
- 2" intake and discharge.
- 56-frame motor for added strength.
- Thermally protected to extend life expectancy of motor.
- California Title 20 Compliant.
Product Specifications:
Speed
2 Speed (2-Spd)
Motor Voltage
230v
Drain Plug Location
4,6,9 o`clock
Pump to Motor Foot Types
9
Suction Style
Center
Suction Connection (Physical Dimension)
3-1/16"od
Suction Connection Type
Male Buttress Thread (mbt)
Suction Pipe Size
2"
Discharge Style
Side
Discharge Connection (Physical Dimension)
3-1/16"od
Discharge Connection Type
Male Buttress Thread (mbt)
Discharge Pipe Size
2"
Horsepower
3.0hp
Motor Frame
56 Frame Thru-Bolt
Motor Amperage/Wattage
12.0A/4.4A
Manufacturer
AquaFlo/Gecko
Pump Model
Flo-Master XP2e
Manufacturer Impeller Number
91695317
Volute Fastening Type
8 Screws
Volute/Sealplate Number
92770705
Warranty Information
12 Months
