Description
CAT: B2234
MODEL: F56AA55A01
TYPE: CXCP
FR: P56Y
HP: 3.0
SF:
PH: 1
HZ: 60
RPM: 3450/1725
ROT: CCWPE
VOLTS: 230
AMPS: 10.0/1.8
MAX AMPS:
SF AMPS: 9.7/1.6
TIME: CONT
ENCL: ODP THERMALLY PROTECTED
FORM: KJM
CODE: J
INSUL CLASS: F
AMB.: 50
PSC on High Speed
E-Plus New Centurion Design
Cap Start/Cap Run on Low Speed
50°C Ambient
3/8-16 UNC-2A Threads Includes Slinger
3-1/2” Shaft Height
Four Thru Bolts on a 5.812 Bolt Circle
Warranty Information
12 Months
